ブロック図 (計測器)

目次

スペクトラムアナライザ

ネットワークアナライザ

信号発生器 / シンセサイザ

オシロスコープ

スペクトラムアナライザ


Function Product Type Holder Status PKG Size (mm) Frequency (Hz) Temp. Range note
Microcontroller SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Microcontroller SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz
Sweep Generator OCXO NH25M22TE MP 25.4 x 22 x 12.1 10M -40 to +85℃ LVCMOS
Digital Signal Processer SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Digital Signal Processer SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz

ネットワークアナライザ


Function Product Type Holder Status PKG Size (mm) Frequency (Hz) Temp. Range note
Microcontroller SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Microcontroller SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz
Digital Signal Processer SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Digital Signal Processer SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz
Sweep Generator OCXO NH25M22TE MP 25.4 x 22 x 12.1 10M -40 to +85℃ LVCMOS

信号発生器 / シンセサイザ


Function Product Type Holder Status PKG Size (mm) Frequency (Hz) Temp. Range note
Synthesizer OCXO NH25M22TE MP 25.4 x 22 x 12.1 10M -40 to +85℃ LVCMOS
Digital Processing SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Digital Processing SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz

オシロスコープ


Function Product Type Holder Status PKG Size (mm) Frequency (Hz) Temp. Range note
Image Processing SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
Image Processing SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz
System Processor SPXO NZ2520SH MP 2.5 x 2.0 x 0.9 1.5 to 170M -40 to +125℃ CMOS
System Processor SPXO NZ2520SDA MP 2.5 x 2.0 x 0.9 48, 52, 54M -40 to +85℃ CMOS, Low Noise -172dBc/Hz@100kHz
Clock Generator OCXO NH25M22TE MP 25.4 x 22 x 12.1 10M -40 to +85℃ LVCMOS
